AMD Ryzen 7 7700X Spec –
| Specification | |
| General Specifications | Platform: Desktop
Market Segment: Enthusiast Desktop Product Family: AMD Ryzen™ Processors Product Line: AMD Ryzen™ 7 Desktop Processors AMD PRO Technologies: No Consumer Use: Yes Regional Availability: Global Former Codename: “Raphael AM5” Architecture: “Zen 4” # of CPU Cores: 8 Multithreading (SMT): Yes # of Threads: 16 Max. Boost Clock: Up to 5.4GHz Base Clock: 4.5GHz L1 Cache: 512KB L2 Cache: 8MB L3 Cache: 32MB Default TDP: 105W Processor Technology for CPU Cores: TSMC 5nm FinFET Processor Technology for I/O Die: TSMC 6nm FinFET CPU Compute Die (CCD) Size: 71mm² I/O Die (IOD) Size: 122mm² Package Die Count: 2 Unlocked for Overclocking : Yes AMD EXPO™ Memory Overclocking Technology: Yes Precision Boost Overdrive: Yes Curve Optimizer Voltage Offsets: Yes AMD Ryzen™ Master Support: Yes CPU Socket: AM5 Supporting Chipsets: X670E. X670, B650E, B650 CPU Boost Technology: Precision Boost 2 Instruction Set: x86-64 Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 Max. Operating Temperature (Tjmax): 95°C *OS Support: Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit, *Operating System (OS) support will vary by manufacturer. |
| Connectivity | USB Type-C® Support: Yes
Native USB 3.2 Gen 2 (10Gbps) Ports: 4 Native USB 3.2 Gen 1 (5Gbps) Ports: 0 Native USB 2.0 (480Mbps) Ports: 1 Native SATA Ports: 0 Native PCIe® Lanes (Total/Usable): 28/24 Additional Usable PCIe Lanes from Motherboard: AMD X670E – 12x Gen4 AMD X670 – 12x Gen4 AMD B650E – 8x Gen4 AMD B650 – 8x Gen4 NVMe Support: Boot, RAID0, RAID1, RAID10 Memory Channels: 2 Max. Memory: 128GB System Memory Subtype: UDIMM Max Memory Speed 1x1R – 5200 MT/s 1x2R – 5200 MT/s 2x1R – 3600 MT/s 2x2R – 3600 MT/s ECC Support: Yes (Requires mobo support) |
| Graphics Capabilities | Integrated Graphics: Yes
Graphics Model: AMD Radeon™ Graphics Graphics Core Count: 2 Graphics Frequency: 2200 MHz GPU Base: 400 MHz USB Type-C® DisplayPort™ Alternate Mode: Yes |
| Key Features | AMD EXPO™ Technology
AMD Ryzen™ Technologies |
| Warranty | 3 Years |
