ViewSonic VA1903h 19” Specification –
|
Display
|
Display Size (in.): 19
Viewable Area (in.): 18.5
Panel Type: TN Technology
Resolution: 1366 x 768
Resolution Type: WXGA (Wide XGA)
Static Contrast Ratio: 600:1 (typ)
Dynamic Contrast Ratio: 50M:1
Light Source: LED
Brightness: 200 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + FRC)
Aspect Ratio: 16:9
Response Time (Typical Tr+Tf): 5ms
Viewing Angles: 90º horizontal, 65º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 60
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 102% size (Typ)
Pixel Size: 0.3 mm (H) x 0.3 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H) |
Compatibility
|
PC Resolution (max): 1366×768
Mac® Resolution (max): 1366×768
PC Operating System: Windows 10/11 certified; macOS tested
Mac® Resolution (min): 1366×768 |
Connector
|
VGA: 1
3.5mm Audio Out: 1
HDMI 1.4: 1
Power in: 3-pin Socket (IEC C14 / CEE22) |
Power
|
Eco Mode (Conserve): 9.5W
Eco Mode (optimized): 12.5W
Consumption (typical): 15.3W
Consumption (max): 17W
Voltage: AC 100-240V
Stand-by: 0.5W
Power Supply: Internal Power Supply |
Additional Hardware
|
Kensington Lock Slot: 1 |
Controls
|
Physical Controls: Auto, Left, Right, Menu, Power
On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall |
Operating Conditions
|
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90% |
Wall Mount
|
VESA Compatible: 75 x 75 mm |
Input Signal
|
Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz
Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 75Hz |
Video Input
|
Digital Sync: TMDS – HDMI (v1.4)
Analog Sync: Separate – RGB Analog |
Ergonomics
|
Tilt (Forward/Back): -3º / 18º |
Weight (imperial)
|
Net (lbs): 4.6
Net Without Stand (lbs): 4
Gross (lbs): 6.6 |
Weight (metric)
|
Net (kg): 2.1
Net Without Stand (kg): 1.8
Gross (kg): 3 |
Dimensions (imperial) (wxhxd)
|
Packaging (in.): 19.8 x 13.7 x 4.1
Physical (in.): 17.2 x 13.5 x 6.7
Physical Without Stand (in.): 17.2 x 10.7 x 1.9 |
Dimensions (metric) (wxhxd)
|
Packaging (mm): 502 x 349 x 105
Physical (mm): 438 x 344 x 170
Physical Without Stand (mm): 438 x 271 x 48 |
General
|
Regulations: cTUVus, FCC-B, ICES003, CEC, IQC-ST, MX-CoC, Mexico Energy, CB, RoHS, WEEE, BIS
PACKAGE CONTENTS: VA1903H x1, 3-pin Plug (IEC C13 / CEE22) x1, VGA Cable (Male-Male) x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market |
