ViewSonic VX2418-P-MHD Specification –
|
Display
|
Display Size (in.): 24
Viewable Area (in.): 23.8
Panel Type: VA Technology
Resolution: 1920 x 1080
Resolution Type: FHD (Full HD)
Static Contrast Ratio: 4,000:1 (typ)
Dynamic Contrast Ratio: 80M:1
Light Source: LED
Brightness: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + FRC)
Aspect Ratio: 16:9
Response Time (MPRT): 1ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 165
Adaptive Sync: FreeSync
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 103% size (Typ)
Pixel Size: 0.275 mm (H) x 0.275 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H) |
Compatibility
|
PC Resolution (max): 1920×1080
Mac® Resolution (max): 1920×1080
PC Operating System: Windows 10/11 certified; macOS tested
Mac® Resolution (min): 1920×1080 |
Connector
|
3.5mm Audio Out: 1
HDMI 1.4: 2
DisplayPort: 1
Power in: 3-pin Socket (IEC C14 / CEE22) |
Audio
|
Internal Speakers: 2Watts x2 |
Power
|
Eco Mode (Conserve): 17W
Eco Mode (optimized): 21W
Consumption (typical): 25W
Consumption (max): 27W
Voltage: AC 100-240V
Stand-by: 0.3W
Power Supply: Internal Power Supply |
Additional Hardware
|
Kensington Lock Slot: 1 |
Controls
|
Physical Controls: Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power)
On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
Operating Conditions
|
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90% |
Wall Mount
|
VESA Compatible: 100 x 100 mm |
Input Signal
|
Frequency Horizontal: HDMI (v1.4): 30 ~ 180KHz, DisplayPort (v1.2): 30 ~ 180KHz
Frequency Vertical: HDMI (v1.4): 50 ~ 144Hz, DisplayPort (v1.2): 50 ~ 165Hz |
Video Input
|
Digital Sync: TMDS – HDMI (v1.4), PCI-E – DisplayPort (v1.2) |
Ergonomics
|
Tilt (Forward/Back): -5º / 20º |
Weight (imperial)
|
Net (lbs): 8.3
Net Without Stand (lbs): 6.6
Gross (lbs): 11.5 |
Weight (metric)
|
Net (kg): 3.8
Net Without Stand (kg): 3
Gross (kg): 5.2 |
Dimensions (imperial) (wxhxd)
|
Packaging (in.): 24.5 x 16.5 x 5.7
Physical (in.): 21.2 x 16.8 x 8.9
Physical Without Stand (in.): 21.2 x 12.7 x 2 |
Dimensions (metric) (wxhxd)
|
Packaging (mm): 622 x 420 x 144
Physical (mm): 540 x 428 x 225
Physical Without Stand (mm): 540 x 323 x 51 |
General
|
Regulations: cTUVus, FCC-B, ICES003, CEC, TUV S-Mark, NOM, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, RCM, GEMS, VCCI, PSE, BIS
PACKAGE CONTENTS: VX2418-P-MHD x1, 3-pin Plug (IEC C13 / CEE22) x1, DisplayPort Cable (v1.2; Male-Male) x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market
Country Of Origin: 60 |
